Building Interactive Data Visualizations in Python: An Introduction to Plotly

Author:Murphy | View: 28808 | Time: 2025-03-23 18:04:20

Data visualization is one of the most important tasks for Data Professionals. It helps us, in fact, understand the data and to ask more questions for further investigations.

But data visualization is not only a task we have to conclude in the Exploratory Data Analysis phase. We may also need to present the data, often to an audience to help it grab some conclusions.

In Python, we generally use matplotlib and seaborn as libraries to plot our graphs.

However, sometimes we may need some interactive visualizations. In some cases, for a better understanding of the data. In some other cases, just to better present our solutions.

In this article, we'll talk about plotly which is a Python library for making interactive visualizations.

What is Plotly?

As we can read on their website:

Plotly's Python graphing library makes interactive, publication-quality graphs. Examples of how to make line plots, scatter plots, area charts, bar charts, error bars, box plots, histograms, heatmaps, subplots, multiple-axes, polar charts, and bubble charts.

Plotly.py is free and open source and you can view the source, report issues or contribute on GitHub.

So, Plotly is a free and open-source Python library for making interactive visualizations.

As we can see on their website, it gives us the possibility to create plots for different scopes: AI/ML, statistical, scientific, financial, and much more.

Since we're interested in Machine Learning and Data Science, we'll show some plots related to this field and how to create them in Python.

Finally, to install it, we have to type:

$ pip install plotly

1. Interactive Bubble charts

One interesting and useful feature of Plotly we can use is the possibility of interactive bubble plots.

In the case of bubble charts, in fact, sometimes the bubbles can intersect, making it difficult to read the data. If the graph is interactive, instead, we can read the data more easily.

Let's see an example:

import plotly.express as px import pandas as pd import numpy as np  # Generate random data np.random.seed(42) n = 50 x = np.random.rand(n) y = np.random.rand(n) z = np.random.rand(n) * 100  # Third variable for bubble size  # Create a DataFrame data = pd.DataFrame({'X': x, 'Y': y, 'Z': z})  # Create the scatter plot with bubble size with Plotly fig = px.scatter(data, x='X', y='Y', size='Z',       title='Interactive Scatter Plot with Bubble Plot')  # Add labels to the bubbles fig.update_traces(textposition='top center', textfont=dict(size=11))  # Update layout properties fig.update_layout(     xaxis_title='X-axis',     yaxis_title='Y-axis',     showlegend=False )  # Display the interactive plot fig.show()

And we get:

The interactive bubble chart we've coded. Image by Federico Trotta.

So, we've created some data with NumPy and stored them in a Pandas data frame. Then, we've created the interactive plot with the method px.scatter() retrieving the data from the data frame, and specifying the title (as opposed to Matplotlib in which we insert the title outside the method used to create the plot itself).

2. Interactive correlation matrices

One of the tasks I sometimes struggle with is a proper visualization of correlation matrices. These, in fact, can sometimes be challenging to read and visualize when we have a lot of data.

One way to solve the problem is to use Plotly to create an interactive visualization.

For the scope, let's create a Pandas data frame with 10 columns and create an interactive correlation matrix with Plotly:

import pandas as pd import numpy as np import plotly.figure_factory as ff  # Create random data np.random.seed(42) data = np.random.rand(100, 10)  # Create DataFrame columns = ['Column' + str(i+1) for i in range(10)] df = pd.DataFrame(data, columns=columns)  # Round values to 2 decimals correlation_matrix = df.corr().round(2)    # Create interactive correlation matrix with Plotly figure = ff.create_annotated_heatmap(     z=correlation_matrix.values,     x=list(correlation_matrix.columns),     y=list(correlation_matrix.index),     colorscale='Viridis',     showscale=True )  # Set axis labels figure.update_layout(     title='Correlation Matrix',     xaxis=dict(title='Columns'),     yaxis=dict(title='Columns') )  # Display the interactive correlation matrix figure.show()

And we get:

The interactive correlation matrix we created. Image by Federico Trotta.

So, in a very simple way, we can create an interactive correlation matrix with the method ff.create_annotated_map().

3. Interactive ML plots

In Machine Learning, we sometimes need to compare quantities graphically. And, in these cases, sometimes it's hard to read our plots.

The typical case is a ROC/AUC curve where we compare the performance of different ML models. Sometimes, in fact, the curves intercepts and we're not able to properly visualize them.

To improve our visualizations, we can use Plotly to create a ROC/AUC curve like so:

import pandas as pd import numpy as np from sklearn.datasets import make_classification from sklearn.model_selection import train_test_split from sklearn.preprocessing import StandardScaler from sklearn.neighbors import KNeighborsClassifier from sklearn.ensemble import RandomForestClassifier from sklearn.tree import DecisionTreeClassifier from sklearn.svm import SVC from sklearn.metrics import roc_curve, auc import plotly.graph_objects as go  # Create synthetic binary classification data X, y = make_classification(n_samples=1000, n_features=20, random_state=42)  # Scale the data using StandardScaler scaler = StandardScaler() X_scaled = scaler.fit_transform(X)  # Split the data into train and test sets X_train, X_test, y_train, y_test = train_test_split(X_scaled, y, test_size=0.2, random_state=42)  # Initialize the models knn = KNeighborsClassifier() rf = RandomForestClassifier() dt = DecisionTreeClassifier() svm = SVC(probability=True)  # Fit the models on the train set knn.fit(X_train, y_train) rf.fit(X_train, y_train) dt.fit(X_train, y_train) svm.fit(X_train, y_train)  # Predict probabilities on the test set knn_probs = knn.predict_proba(X_test)[:, 1] rf_probs = rf.predict_proba(X_test)[:, 1] dt_probs = dt.predict_proba(X_test)[:, 1] svm_probs = svm.predict_proba(X_test)[:, 1]  # Calculate the false positive rate (FPR) and true positive rate (TPR) for ROC curve knn_fpr, knn_tpr, _ = roc_curve(y_test, knn_probs) rf_fpr, rf_tpr, _ = roc_curve(y_test, rf_probs) dt_fpr, dt_tpr, _ = roc_curve(y_test, dt_probs) svm_fpr, svm_tpr, _ = roc_curve(y_test, svm_probs)  # Calculate the AUC (Area Under the Curve) for ROC curve knn_auc = auc(knn_fpr, knn_tpr) rf_auc = auc(rf_fpr, rf_tpr) dt_auc = auc(dt_fpr, dt_tpr) svm_auc = auc(svm_fpr, svm_tpr)  # Create an interactive AUC/ROC curve using Plotly fig = go.Figure() fig.add_trace(go.Scatter(x=knn_fpr, y=knn_tpr, name='KNN (AUC = {:.2f})'.format(knn_auc))) fig.add_trace(go.Scatter(x=rf_fpr, y=rf_tpr, name='Random Forest (AUC = {:.2f})'.format(rf_auc))) fig.add_trace(go.Scatter(x=dt_fpr, y=dt_tpr, name='Decision Tree (AUC = {:.2f})'.format(dt_auc))) fig.add_trace(go.Scatter(x=svm_fpr, y=svm_tpr, name='SVM (AUC = {:.2f})'.format(svm_auc))) fig.update_layout(title='AUC/ROC Curve',                   xaxis=dict(title='False Positive Rate'),                   yaxis=dict(title='True Positive Rate'),                   legend=dict(x=0.7, y=0.2)) # Show plot fig.show()

And we get:

The AUC/ROC curve we've created. Image by Federico Trotta.

So, with the method add.trace(go.Scatter) we've created scatterplots for each ML model we've used (KNN, SVM, Decision Tree, and Random Forest).

This way, it's easy to display the details and the values of the zones where the curves intercept themselves.

Conclusions

In this article, we've shown a quick introduction to Plotly and we've seen how we can use it for better visualizations in data analysis and Machine Learning.

As we can see, this is a low-code library that, indeed, helps us better visualize our data, improving our results.
